Passport Box Aspect Ratio and Resolution

  1. Last updated
  2. Save as PDF


Aspect Ratio and Resolution

Unsure of the User Interface on your TV? Click here



  • Aspect Ratio is the proportion between the width and height of a TV screen

  • Resolution defines the amount of pixels displayed on the screen

    • 4K (Available on some TiVos)

    • 1080p  (Available on TiVo)

    • 1080i

    • 720p

    • 480i (Standard Definition)

    • i or p refers to the scanning technology

      • i = Interlaced scanning technology. It scans and refreshes even and odd lines separately, but produces very sharp pictures in general when the image is still or has little motion

      • p = Progressive scanning technology (newer). Scans and refreshes all lines at the same time. Progressive scanning produces smoother motion with less blurring. It's perfect for high action movies and sports.


Passport ECHO (DVR)

4:3 HDTV (Square)

  1. On the remote, press Menu twice for the Settings Menu

  2. Scroll to and select Audio/Video, then Video Output Format

  3. Choose 480p Std and arrow right to select Zoom or Letterbox, then press OK/SELECT to confirm changes

    • Zoom: 4:3 Standard programs display normally; 16:9 HD programs are cropped to fill the screen

    • Letterbox: 4:3 Standard programs display borders on all sides to maintain the image; 16:9 HD programs display borders on top and bottom

  4. Press OK/SELECT again to accept the change; if the display doesn't change after 15 seconds, the selected output is not supported by the customer's TV

  5. You can also change the color of the left and right borders




16:9 HDTV (Widescreen)

  1. On the remote, press Menu twice for the Settings Menu

  2. Scroll to and select Audio/Video, then Video Output Format

  3. Choose 1080i Wide and arrow right to select Preserve, Stretch or Sidebar, then press A to confirm changes

    1. Preserve 4:3 Pic - 480i / 480p: 4:3 Standard programs display with borders on the left and right side

    2. Stretch 4:3 Pic: widens 4:3 Standard programs to fit the a 16:9 screen

    3. Sidebar 4:3 Pic: zooms in on 4:3 Standard programs to crop the top and bottom

    4. This graphic explains the process

  4. Press A again to accept the change; if the display doesn't change after 15 seconds, the selected output is not supported by the customer's TV


Passport / Passport DCT (Standard Digital boxes)

4:3 HDTV (Square)

  1. On the remote, press Menu twice for the Settings Menu and select Output Formats

  2. Choose 720p or 1080i and arrow right to select Zoom or Letterbox, then press A to confirm changes

    • Zoom: 4:3 Standard programs display normally; 16:9 HD programs are cropped to fill the screen

    • Letterbox: 4:3 Standard programs display borders on all sides to maintain the image; 16:9 HD programs display borders on top and bottom

  3. Press A again to accept the change; if the display doesn't change after 15 seconds, the selected output is not supported by the customer's TV




16:9 HDTV (Widescreen)

  1. On the remote, press Menu twice for the Settings Menu and select Output Formats

  2. Choose 720p or 1080i and arrow right to select Preserve, Stretch or Sidebar, then press A to confirm changes

    • Preserve 4:3 Pic - 480i / 480p: 4:3 Standard programs display with borders on the left and right side

    • Stretch 4:3 Pic: widens 4:3 Standard programs to fit the a 16:9 screen

    • Sidebar 4:3 Pic: zooms in on 4:3 Standard programs to crop the top and bottom

    • This graphic explains the process

  3. Press A again to accept the change; if the display doesn't change after 15 seconds, the selected output is not supported by your TV
